Roof & Wall Panel Profiles

Click on the profile name below to open a detail drawing.



SS100

Panel seam: 1” high



Panel material: 28 ga. to 22 ga. steel (painted, Galvalume, coated galvanized, aluminized)*, .027" to .040" aluminum/painted, and 16 oz. to 20 oz. 3/4 hard copper



Panel coverage: 12” to 24” for SSQ and 12” to 17” for SSR



Machines that make this profile: SSQ II and SSR











SSQ210A

Panel seam: 2” high



Panel material: 28 ga. to 22 ga. steel (painted, Galvalume, coated galvanized), .027" to .040" aluminum (painted), and 16 oz. to 20 oz. 3/4 hard copper



Panel coverage: 12” to 24”



Machines that make this profile: SSQ II











SSQ550

Panel seam: 1 1/2” high



Panel material: 28 ga. to 22 ga. steel (painted, Galvalume, coated galvanized), .027" to .040" aluminum (painted), and 16 oz. to 20 oz. 3/4 hard copper



Panel coverage: 12” to 24”



Machines that make this profile: SSQ II











FF150

Panel seam: 1 1/2” high



Panel material: 28 ga. to 22 ga. steel (painted, Galvalume, coated galvanized, aluminized)*, .027" to .040" aluminum/painted, and 16 oz. to 20 oz. 3/4 hard copper



Panel coverage: 12” to 24” for SSQ and 10” to 14 11/16” on SSR



Machines that make this profile: SSQ II and SSR











SSQ275

Panel seam: 2” high



Panel material: 26 ga to 22 ga steel/painted steel or .024” to .040” aluminum/painted aluminum



Panel width: 12” to 24”



Machines that make this profile: SSQ II











5VC-210P

Panel material: 30 ga. to 24 ga. steel (painted, Galvalume, coated galvanized), .027" to .040" aluminum (painted), and 16 oz. to 20 oz. 3/4 hard copper



Panel coverage: 21"



Machines that make this profile: 5VC-5V CRIMP Roof Panel Machine











WAV-8-1F Profile

Panel material: 24 ga.-22 ga. painted steel, .032”-.040”  painted aluminum



Panel coverage: 8"



Machines that make this profile: WAV Wall Panel Machine











WAV-16-3F Profile

Panel material: 24 ga.-22 ga. painted steel, .032”-.040”  painted aluminum



Panel coverage: 16"



Machines that make this profile: WAV Wall Panel Machine









SS150

Panel seam: 1 1/2” high



Panel material: 28 ga. to 22 ga. steel (painted, Galvalume, coated galvanized, aluminized)*, .027" to .040" aluminum/painted, and 16 oz. to 20 oz. 3/4 hard copper



Panel coverage: 12” to 24” for SSQ and 11” to 16” for SSR



Machines that make this profile: SSQ II and SSR











SS450

Panel seam: 1 1/2” high



Panel material: 28 ga. to 22 ga. steel (painted, Galvalume, coated galvanized, aluminized)*, .027" to .040" aluminum/painted, and 16 oz. to 20 oz. 3/4 hard copper



Panel coverage: 12” to 24” on SSQII and 11” to 15 7/8” on SSR



Machines that make this profile: SSQ II and SSR











SSQ675

Panel seam: 1 3/4” high



Panel material: 28 ga. to 22 ga. steel (painted, Galvalume, coated galvanized), .027" to .040" aluminum (painted), and 16 oz. to 20 oz. 3/4 hard copper



Panel coverage: 12” to 24”



Machines that make this profile: SSQ II











T-Panel

Panel seam: 1/2” to 2” (leg height is profile dependant)



Panel material: 28 ga. to 22 ga. steel (painted, Galvalume, coated galvanized, aluminized)*, .027" to .040" aluminum/painted, and 16 oz. to 20 oz. 3/4 hard copper



Machines that make this profile: SSQ II and SSR









FWQ100

Panel seam: 1” high



Panel material: 28 ga. to 22 ga. steel (painted, Galvalume, coated galvanized), .027" to .040" aluminum (painted), and 16 oz. to 20 oz. 3/4 hard copper



Panel width: 12” to 22”; 25” maximum coverage with 3” reveal



Machines that make this profile: SSQ II











5VC-240P

Panel material: 30 ga. to 24 ga. steel (painted, Galvalume, coated galvanized), .027" to .040" aluminum (painted), and 16 oz. to 20 oz. 3/4 hard copper



Panel coverage: 24"



Machines that make this profile: 5VC-5V CRIMP Roof Panel Machine











WAV-12-1F Profile

Panel material: 24 ga.-22 ga. painted steel, .032”-.040”  painted aluminum



Panel coverage: 12"



Machines that make this profile: WAV Wall Panel Machine











WAV-16-4F Profile

Panel material: 24 ga.-22 ga. painted steel, .032”-.040”  painted aluminum



Panel coverage: 16"



Machines that make this profile: WAV Wall Panel Machine









SSQ200

Panel seam: 2” high



Panel material: 28 ga. to 22 ga. steel (painted, Galvalume, coated galvanized), .027" to .040" aluminum (painted), and 16 oz. to 20 oz. 3/4 hard copper



Panel coverage: 12” to 24”



Machines that make this profile: SSQ II











SS450SL

Panel seam: 1 1/2” high



Panel material: 28 ga. to 22 ga. steel (painted, Galvalume, coated galvanized, aluminized)*, .027" to .040" aluminum/painted, and 16 oz. to 20 oz. 3/4 hard copper



Panel coverage: 12” to 24” on SSQII and 11” to 15 5/8” on SSR



Machines that make this profile: SSQ II and SSR











FF100

Panel seam: 1” high



Panel material: 28 ga. to 22 ga. steel (painted, Galvalume, coated galvanized, aluminized)*, .027" to .040" aluminum/painted, and 16 oz. to 20 oz. 3/4 hard copper



Panel coverage: 12” to 24” for SSQ and 11” to 16” on SSR



Machines that make this profile: SSQ II and SSR











TRQ250

Panel seam: 2 1/2” high



Panel material: 26 ga to 22 ga steel/painted steel or .024” to .040” aluminum/painted aluminum



Panel width: 14” to 24”



Machines that make this profile: SSQ II









FWQ150

Panel seam: 1 1/2” high



Panel material: 28 ga. to 22 ga. steel (painted, Galvalume, coated galvanized), .027" to .040" aluminum (painted), and 16 oz. to 20 oz. 3/4 hard copper



Panel width: 12” to 22”; 25” maximum coverage with 3” reveal



Machines that make this profile: SSQ II











5VC-245P

Panel material: 30 ga. to 24 ga. steel (painted, Galvalume, coated galvanized), .027" to .040" aluminum (painted), and 16 oz. to 20 oz. 3/4 hard copper



Panel coverage: 24 1/2”



Machines that make this profile: 5VC-5V CRIMP Roof Panel Machine











WAV-16-2F Profile

Panel material: 24 ga.-22 ga. painted steel, .032”-.040”  painted aluminum



Panel coverage: 16"



Machines that make this profile: WAV Wall Panel Machine











WAV-16-4C Profile

Panel material: 24 ga.-22 ga. painted steel, .032”-.040”  painted aluminum



Panel coverage: 16"



Machines that make this profile: WAV Wall Panel Machine















Gutter Profiles

Click on the profile name below to open a detail drawing.







MG5-SB5 - 5"
with Straight Back

Gutter material: 30 ga. to 24 ga. steel (painted, Galvalume, coated galvanized), .019“ to .032” painted aluminum, or 16 oz. to 20 oz. copper 3/4 hard



Gutter size: 5"



Machines that make this profile: MACH II 5” and MACH II 5”/6”











MG5-BF5 - 5"
with Back Flange

Gutter material: 24 ga. steel



Gutter size: 5"



Machines that make this profile: MACH II 5”











MG6-BB6 - 6"
with Bottom Bead

Gutter material: 30 ga. to 24 ga. steel (painted, Galvalume, coated galvanized), .019“ to .032” painted aluminum, or 16 oz. to 20 oz. copper 3/4 hard



Gutter size: 6"



Machines that make this profile: MACH II 6” and MACH II 5”/6”











MG7-SB - 7"
with Straight Back

Gutter material: 24 ga. steel (painted, Galvalume, coated galvanized), .032” to .040” painted aluminum



Gutter size: 7"



Machines that make this profile: MACH II 7”/8”











BG7-SB7 with Hook

Gutter material: 26 ga. to 22 ga. steel (painted, coated galvanized, aluminized), .032” to .050” painted aluminum, 20 oz. to 24 oz. copper 3/4 hard



Gutter size: 7"



Machines that make this profile: BG7











Inset Step

Gutter material: 26 ga. steel (painted, Galvalume, galvanized, aluminized, ternecoat), .032” aluminum, 16 oz. copper 3/4 hard



Gutter size: 5” and 6”



Machines that make this profile: Nasser











Crown Mold

Gutter material: 26 ga. steel (painted, Galvalume, galvanized, aluminized, ternecoat), .032” aluminum, 16 oz. copper 3/4 hard



Gutter size: 5” and 6”



Machines that make this profile: Nasser









MG5-HK5 - 5"
with Alcoa Hook

Gutter material: 30 ga. to 24 ga. steel (painted, Galvalume, coated galvanized), .019“ to .032” painted aluminum, or 16 oz. to 20 oz. 3/4 hard copper



Gutter size: 5"



Machines that make this profile: MACH II 5” and MACH II 5”/6”











MG6-SB6 - 6"
with Straight Back

Gutter material: 30 ga. to 24 ga. steel (painted, Galvalume, coated galvanized), .019“ to .032” painted aluminum, or 16 oz. to 20 oz. copper 3/4 hard



Gutter size: 6"



Machines that make this profile: MACH II 6” and MACH II 5”/6”











MG6-BF10 - 6"
with Back Flange (1")

Gutter material: 30 ga. to 24 ga. steel (painted, Galvalume, coated galvanized), .019“ to .032” painted aluminum, or 16 oz. to 20 oz. copper 3/4 hard



Gutter size: 6"



Machines that make this profile: MACH II 6”











MG8-SB - 8"
with Straight Back

Gutter material: 24 ga. steel (painted, Galvalume, coated galvanized), .032” to .040” painted aluminum



Gutter size: 8"



Machines that make this profile: MACH II 7”/8”











One Step

Gutter material: 26 ga. steel (painted, Galvalume, galvanized, aluminized, ternecoat), .032” aluminum, 16 oz. copper 3/4 hard



Gutter size: 5” and 6”



Machines that make this profile: Nasser











Box Bottom

Gutter material: 26 ga. steel (painted, Galvalume, galvanized, aluminized, ternecoat), .032” aluminum, 16 oz. copper 3/4 hard



Gutter size: 5” and 6”



Machines that make this profile: Nasser











Colonial

Gutter material: 26 ga. steel (painted, Galvalume, galvanized, aluminized, ternecoat), .032” aluminum, 16 oz. copper 3/4 hard



Gutter size: 5” and 6”



Machines that make this profile: Nasser









MG5-BB5 - 5"
with Bottom Bead

Gutter material: 30 ga. to 24 ga. steel (painted, Galvalume, coated galvanized), .019“ to .032” painted aluminum, or 16 oz. to 20 oz. 3/4 hard



Gutter size: 5"



Machines that make this profile: MACH II 5” and MACH II 5”/6”











MG6-HK6 - 6"
with Alcoa Hook

Gutter material: 30 ga. to 24 ga. steel (painted, Galvalume, coated galvanized), .019“ to .032” painted aluminum, or 16 oz. to 20 oz. 3/4 hard copper



Gutter size: 6"



Machines that make this profile: MACH II 6” and MACH II 5”/6”











MG6-BF15 - 6"
with Back Flange (1.5")

Gutter material: 30 ga. to 24 ga. steel (painted, Galvalume, coated galvanized), .019“ to .032” painted aluminum, or 16 oz. to 20 oz. copper 3/4 hard



Gutter size: 6"



Machines that make this profile: MACH II 6”











BG7-SB7 with Straight Back

Gutter material: 26 ga. to 22 ga. steel (painted, coated galvanized, aluminized), .032” to .050” painted aluminum, 20 oz. to 24 oz. copper 3/4 hard



Gutter size: 7"



Machines that make this profile: BG7











Two Step

Gutter material: 26 ga. steel (painted, Galvalume, galvanized, aluminized, ternecoat), .032” aluminum, 16 oz. copper 3/4 hard



Gutter size: 5” and 6”



Machines that make this profile: Nasser











Quad Step

Gutter material: 26 ga. steel (painted, Galvalume, galvanized, aluminized, ternecoat), .032” aluminum, 16 oz. copper 3/4 hard



Gutter size: 5” and 6”



Machines that make this profile: Nasser











Triple Cove

Gutter material: 26 ga. steel (painted, Galvalume, galvanized, aluminized, ternecoat), .032” aluminum, 16 oz. copper 3/4 hard



Gutter size: 5” and 6”



Machines that make this profile: Nasser















Clip Relief / Rib Rollers

Standard feature for most roof panel profiles



Clip Relief



Bead Ribs (Standard or Wide)



Pencil Ribs (Small or Large)



V-Ribs (Small or Large)



Striation Ribs






*Depending on the machine used



Profile Disclaimer: New Tech Machinery provides no warranty (finish, substrate or weather tight) in relation to the metal roofing systems the machines form. Should a warranty be required, users should consult with metal roof manufacturer or coil supplier prior to contracting on work. It is the sole responsibility of the installer and/or metal panel manufacturer to ensure that the roof system meets all engineering and local building codes.
